Optimized Toggle Micro-Travel Limit Switch XCKJ10513H29C 2P, 1NC 1NO Momentary Spring Roller Rocker

Main informationSerial NumberStandard typeproduct typeLimit switchProduct short nameXCKJSensor designType A according to CENELEC EN 50041Ontology typeFixedJoystick typeRotating headmaterialmetalBody materialZamakHead materialZamakFixed modeBy the ontologyManipulator movementSpinOperator typeSpring roller rocker metalMethod typeSide motion, programmable in 1 or 2 directionsCable entry hole1 for M20x1.6 cable gland, cable outer diameter: 7 13 mmNumber of poles2 Contact type1 NC + 1 NOContact actionInstantaneousAdditional informationSwitch trigger30 ° convex edgeElectrical connectionsScrew clamp terminal, clamping force: 1 x 0.34 ... 2 x 1.5 mm²Contact insulation formZbStep count1 Force openHaveForced opening minimum 0.5 NmMin triggering 0.25 NmOperating speed1.5 m / sRated operating current [Ie]3 A at 240 V, AC-15, A300 conforming to EN / IEC 60947-5-1 Appendix A 0.27 A at 250 V, DC-13, Q300 conforming to EN / IEC 60947-5-1 Annex AConventional closed heating current [Ithe]10 ARated insulation voltage [Ui]300 V conforming to UL 508 500 V (pollution degree 3) conforming to IEC 60947-1 300 V conforming to CSA C22.2 No 14maximum resistance across terminals25 M conforming to IEC 60255-7 safety level 3Rated impulse withstand voltage [Uimp]6 kV conforming to IEC 60664 6 kV conforming to IEC 60947-1Short circuit protection10 A fuse, fuse type gGElectrical life<;60 cycles / min, load factor: 0.5 conforming to IEC 60947-5-1 Appendix C <;60 cycles / minute, load factor: 0.5 conforming to IEC 60947-5-1 Appendix C <;60 times / minute, load factor: 0.5 conforming to IEC 60947-5-1 Appendix CMechanical life30000000 timeswidth40 mmheight77 mmdepth44 mmproduct weight0.49 kgISO n ° 1 terminal(21-22) NC (13-14) NOsurroundingsImpact resistance50 gn for 11 ms conforming to IEC 60068-2-27Anti-vibration25 gn (f = 10 500 Hz) conforming to IEC 60068-2-6IP protection levelIP66 according to IEC 60529IK protection levelIK07 according to EN 50102Over voltage typeClass I according to IEC 61140 Class I according to NF C 20-030Operating temperature-25 ... 70 ° CAmbient storage temperature-40 70 ° CProtective treatmentTCcertified productCCCStandards compliantCENELEC EN 50041 CSA C22.2 No 14 EN 60204-1 IEC 60204-1 IEC 60947-5-1 UL 508 EN 60947-5-1==========Current : 3AMaterial : aluminium alloySwitch Type : MICRO SWITCHModel Number : XCKJ10513H29CItem Type : SWITCHESFeatures : metal shell

• Optimized Toggle Micro-travel Limit Switch XCKJ10513H29C 2P, 1NC 1NO Momentary Spring Roller Rocker
